We are a professional manufacturer of special trucks, offering a variety of customizable options to meet customer requirements.
Features:
Capacity: 3-25m3 garbage truck
Steering Wheel: Available in both left and right-hand drive to accommodate different countries
Emission Standard: Options include Euro 1, Euro 2, Euro 3, Euro 4, and Euro 5 garbage trucks
Truck Chassis: Choose from Japan and China brand options
Product Parameters
Product Name | Hook Lift Garbage Truck |
Model | LH5250ZQSC6 |
Chassis No. | ZZ5256 |
Driving Type | 6*4 |
Gross Weight | 25000kg |
Related Loading Mass | 13840kg |
Curb Weight | 11030kg |
Dimension | 8310*2550*3180mm |
Wheelbase | 4350+1350(mm) |
Front Axle Loading Capacity | 5000kg |
Rear Axle Loading Capacity | 10000kg |
Approach angle | 20° |
Departure angle | 13° |
Front Suspension | 1130mm |
Rear Suspension | 2140mm |
Tire | 11.00R20.8+1 PCS |
Max Speed | 100 (Km/h) |
Engine parameters: | |
Model | |
Horse Power | 350hp |
Displacement | 7700cc |
Emission Standard | Euro IV |
Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling) |
Gear Box | |
Gear Box | 8 forward and 1 reverse |
Superstructure Parameter: | |
Tank Volume | 15m3 |
Tank Shape | Arc-shape |
Tank Material thickness | Bottom:3mm Side:3mm |
Tank Material | T420(Special Steel) |
Compression Ratio | ≥2.5 |
The effective volume of the bucket | ≥0.8m³ |
Loading cycle time | ≤40 s |
unload garbage time | ≤45s |
control method | Automatic,Manual |
Maximum pressure of hydraulic system | 20MPa |
Control System | Siemens PLC |
Engine power control | Fully automatic control |
Tumbler mechanism | 240L Garbage bin(Others Optional) |
