CLW Garbage Truck Manufacturer

Dongfeng 4x2 12m3 Garbage Compression Truck

$ 29,800

We can supply 2-25CBM Compactor garbage truck and the China compactor garbage trucks already were exported to more than 30 countries. Competitive price with high quality always accompany with our compactor garbage truck.Rubbish compactor parametersCabinLong cab,A/CVehicle DimensionsOverall dime...

󦌡Contact Now

Products Pictures

Product Detail

Rubbish compactor parameters

Cabin	Long cab,A/C
Vehicle Dimensions	Overall dimensions (L x W x H) mm	8850×2500×3120
	Wheel base (mm)	4700
	Wheel track (front/rear) (mm)	1876/1820
Truck weight (KGS)	Tare weight	10700
	Recommend payload	12000
	Front axles load capacity	6500
	Rear axles load capacity	11500
Max. driving speed(km/h)		89
Engine	Brand	Dongfeng Cummins engine
	Model	B190 33
	Type	4 stroke,straight 6-cylinder in line,Turbocharge with inter-cooling,diesel engine
	Engine dispacement(L) Horse Power(HP)	Engine displacement: 5.9L 190HP, other engine power are optional
	Emission standard	Euro 3
Gearbox	Manual operation,6 speed forward and 1 reverse gear
Steering	Hydraulic steering with power assistance
Clutch	Reinforced diaphragm clutch
Tire	10.00R20 tyre, 6+1 pcs (including one spare tire)

The special parameter of compression garbage compactor truck

Garbage container effective volume	About 12-14 cubic meter
Body shape	The new Arc
The body material	Q345 manganese steel (side:4mm, base flloor: 5mm)
Compression ratio	1:2.5 or higher
Dirty water collection tank volume	Range from 200 liters-500 liters
Effective volume of hopper	0.8-1.2 CBM or higher per client's required
Loading cycle time	40s or less
Discharge cycle time/shovel rise time	45s or less
Tailgate ascending angle	about 95 degree
The control mode	Automatic, manual
Hydraulic system pressure	18MPa
Multiple directional controlvalve	Jiangsu oil valve in China,or import parts
Hydraulic oil pump	Hefei pump in China,or import parts
Conversion force retractor	Zhejiang jiashan in China,or import parts
Electronic control system (PLC one-button cycle)	Made from Taiwan China,or import parts
Trash bin suspension type	Rear suspension for 120L,240L,1100L trash bin

 Dongfeng Garbage Compactor Trucks 4x2 Garbage Compactor Trucks

Company Profile

CLW Group is a top 500 corporation in China,focusing on special vehicles manufacturing since 1988.The company has an annual production capacity of 100.000 special trucks including LPG tanker trucks,fire trucks,water trucks,garbage trucks,truck-mounted crane,tow trucks,ambulance and other special vehicles.

We can produce many kinds of garbage trucks, including skip loader garbage truck, compactor garbage truck, garbage collection truck, garbage transportation truck, container garbage truck, hydraulic lifter garbage truck, self-loading garbage truck, arm-roll garbage truck, hanging bin garbage truck, dump garbage truck, hermetic garbage truck, sealed garbage truck, arm shaking garbage truck, etc.

The registered trademark of which is "Chengliwei", and the product code is "CLW". It's the important partner of Dongfeng and Jiefang. And mainly engaged in manufacturing all kinds of special vehicles and selling full vehicle and fittings to large-scale manufacturers.

The company is a hightech enterprise in hubei province and has passed the certification of ISO9001,ISO16949,GJB9001 and CCC authentication of automobile products.

Advantages of our products

1.Our company ChengLi Special Automobile Co.,LTD has manufactured special truck for decades.

2.Our company possesses some advanced technologies and mature craftworks.

3.The truck produced by us has high quality and low price.

4.Our trucks are equiped with high quality and efficient equipments.

5.Our trucks are completely produced according to your demands and needs, they are special, professional and unique for you.

FAQ

1. Q: How about the quality of trucks of your factory?

A: Our trucks get ISO 9001: 2008 and CCC, B&V and other related certificates. The chassis and spare parts come from the original manufacturers with anti-fake label.

2. Q: How many years of your company's service, especially after-sale service?

A:CLW group has been in this field for nearly 15 years and has strong production and distribution capability, we can produce your products in 15 working days. We offer 1 year after-sale service.

3. Q: Is there any advantages of your price?

A: CLW Group is one of the most important suppliers of Sinotruk, Shacman, Dongfeng, FOTON and FAW, which provides guarantees for reasonable price and good quality.

4. Price term: FOB, CIF.

5. Payment: 30% deposit after order confirmation, 70% balance should be paid before delivery. All are by T/T, L/C.

6. Delivery time: 25 working days after payment is received.

7. Standard Steering: Left-hand drive, if you need Right-hand drives, please inform us, will make special order for you.
