Refrigerator truck is widely used for transporting frozen foods, dairy products, fruits, vegetables, vaccine drugs etc, which is equipped with refrigeration unit and polyurethane insulation compartment.
Refrigerator truck for sale has Sinotruk howo truck, Isuzu truck, Dongfeng truck, Faw truck, Foton truck and Jac truck according to the chassis classification. Refrigerator trailer has two axle trailer and three axle trailer.
As the refrigerator truck manufacturer, CLW GROUP are specialized in manufacturing 3ton-60ton refrigerator truck/trailer and exports a large number of trucks/trailers abroad every year. Our high quality refrigerator trucks have a competitive advantage in the market both in price and quality.
ITEM | PARAMETER | UNIT | DATA |
Whole Vehicle | Overall Dimensions | mm | 5995*2120*3130 |
Van Compartment | mm | 4015*1900*2000 | |
Curb Weight | kg | 4456 | |
Max Speed | km/h | 110 | |
Front/Rear Hanging | mm | 1120/1515 | |
Approach/Departure Angle | ° | 22/17 | |
Leaf Spring | pcs | 3+1/6+7 | |
Drive Wheel | 4*2 | ||
Chassis Model | HFC5041XLCP73K1C7S | ||
Manufacturer | JAC Motor Co., Ltd. | ||
Wheel Base | mm | 3365 | |
Tire Specification | inch | 7.50-16 14PR | |
No. of Tires | pcs | 6 | |
Engine | Engine Type | ISF3.8s5154 | |
Engine Horsepower | hp | 130 | |
Displacement | ml | 2780 | |
Emission Standard | EuroIV | ||
Cab | Row | Single Row | |
Passenger | 2.3 | ||
Equipment | With air conditioner | ||
Van Body | Material | Fiberglass steel plate | |
Normal refrigerated unit | HanXue Brand | With -18degrees C |
